- QR Code Format : QR code 10mil,15mil, 20mil (Code 11/39/93/128/EAN128/Interleaved 2of 5/Matrix 2 of 5).
- QR Code Read Range : Reading range for 6-30cm.
- QR Code Read Angle : Directional 360° , Tilt +/-65° , Deflection +/-60°.
- QR Code Scan Angle : Horizontal 28° , Vertical 21.5°.
- RF Frequency : 13.56Mhz for ISO14443 type A standard.
- RFID Read Range : For up to 5cm with RFID Mifare proximity card.
- Reading Time : Less than 200 ms.
- Data Output format : 34 bits wiegand output format.
- Audio/visual Indication : Red, Blue & Green LED and Beeper indication.
- Casing Colors : Black with Silver colors.
- Dimensions : 115 mm x 75 mm x 22 mm.
- Operating Environment : Indoor with normal lighting condition.
- Operating Temperature : -20° to 60° C.
- Operating Humidity : 5 to 95% relative humidity non-condensing
- Power Requirements : DC12V at 500mA.
- Cable Distance : Wiegand interface: 500 feet (150 m)
|
|
